EPP Boost DC Transformer
$7,896.00
Excluding Tax
Our line of EV Boost DC Transformers ensures safe and efficient EV charging by matching the existing power supply voltage to the voltage requirements of your EV charger.
A location assessment by a qualified certified Electrical Engineer is required prior to purchase of DC chargers or Transformers.This thorough evaluation determines the compatibility with your site infrastructure and provides tailored recommendations for upgrades if necessary. This is also vital for estimating installation costs.
Call to setup an assessment today.
product info
| Basics | Model | ATO-SG60KVA |
| Phase | 3 phase | |
| Capacity | 60 kVA | |
| Weight of Aluminium Wire Transformer | Open type: 268kg Protected type: 335kg |
|
| Weight of Copper Wire Transformer | Open type: 275kg Protected type: 345kg |
|
| Technical Parameters | Primary Voltage | 190V (Optional: 190V/ 208V/ 220V/ 230V/ 240V/ 380V/ 400V/ 415V/ 480V) |
| Secondary Voltage | 400V (Optional: 190V/ 208V/ 220V/ 230V/ 240V/ 380V/ 400V/ 415V/ 480V) | |
| Voltage Convert | Three phase to three phase | |
| Frequency | 50Hz / 60 Hz | |
| Winding Material | Aluminium/Copper wire (Optional) | |
| Work Efficiency | ≥95% | |
| Insulation Resistance | ≥50 MΩ | |
| Electrical Strength | 3000V AC/1 min | |
| Noise | <35-65dB (1 meter) | |
| Insulation Grade | H level | |
| Wiring Mode | Dyn11 | |
| Cooling Mode | Dry type air cooling | |
| Overload Capacity | Allow more than 1.2 times rated load to work for up to 4 hours | |
| Enclosure Protection Grade | IP 24 | |
| Certificate | CE, ISO | |
| Warranty | 12 months | |
| Working Environment | Temperature | -15℃~+40℃ |
| Humidity | ≤90%RH, without condensation | |
| Altitude | <1000m, non corrosive gas and conductive dust |
